Program with a Keypad

Programming

DMP panels do not require an external programmer. You can program through a DMP alphanumeric keypad, Dealer Admin, Tech APP, and Remote Link. Refer to the XR programming guide for more information.

Enter Panel Programmer

1. Reset the panel using the Reset Jumper.

2. Enter 6653 (PROG) and press CMD.

3. Press CMD to navigate through the panel programmer menus. The following menus are available:

   • Initialization

   • Communication

   • Network Options

   • Device Setup

   • Remote Options

   • System Reports

   • System Options

   • Bell Options

   • Output Options

   • Output Information

   • Output Groups

   • Status List

   • Menu Display

   • PC Log Reports

   • Area Information

   • Zone Information

   • Stop

   • Set Lockout Code

   • Feature Upgrade

Select Communication Type

1. Navigate to Communication and press a top-row select key or area.

2. Press a top-row select key or area to clear the default Account Number.

3. Enter in an Account Number.

4. Press CMD to navigate to Path.

5. Press 1 to program Path 1.

6. Press a top-row select key or area to display the communication types.

7. Select a communication type.

8. Press CMD to exit Communication.

Add a Keypad

1. Navigate to Device Setup and press a top-row select key or area.

2. Enter a Device Number and press CMD.

3. Press a top-row select key or area and enter a Device Name.

4. Press CMD to confirm the Device Type.

5. Press CMD to exit Device Setup.

Add a 734 Interface Module

1. Connect the 734 module to the Keypad Bus.

2. Use the dip switches on the 734 to address the module.

3. Reset the panel and enter 6653 (PROG) to enter the panel programmer.

4. Using CMD, navigate to Device Setup.

5. Program the 734 at the same address set with the dip switches.

6. Press a top-row select key or area to name the device.

7. Press a top-row select key or area to program the Device Type as a Door.

8. Assign Access Area 2.

9. Set Public Door, Fire Exit, and Door Real-Time Status to YES.

10. Connect the reader to Terminals 1-4 on the 734.

11. Connect the POSITIVE terminal on the external power supply to the C (Common) terminal on the 734.

12. Connect the NEGATIVE terminal on the door strike to the NEGATIVE terminal on the external power supply.

13. Connect the POSITIVE terminal on the door strike to the NO (Normally Open) terminal on the 734.

14. Install the Module 333 Suppressor between the C and NO terminals on the 734.

Adjust the Keypad Address

Graphic Touchscreen Keypad

1. Select Options from the carousel.

2. Select the Installer Options icon.

3. Enter 3577 (INST) and press CMD.

4. Select Keypad Options (KPT OPT).

5. Press a top-row select key or area and enter a new Keypad Address.

6. Press CMD to exit Keypad Options.

7. Select Stop to save keypad programming.

Thinline Keypad

1. Press and hold the Back Arrow and CMD for 2 seconds.

2. Enter 3577 (INST) and CMD.

3. Select Keypad Options (KPD OPT).

4. Press a top-row select key or area to change the Keypad Address.

5. Press CMD to exit Keypad Options.

6. Select Stop to save keypad programming.

Configure System Options

1. Navigate to System Options and press a top-row select key or area.

2. Press CMD to navigate to Entry Delay 1.

3. Press a top-row select key or area and choose a time from 30 to 250 seconds.

4. Repeat this process for Entry Delay 2.

5. Press CMD to navigate to Hours from GMT.

6. Press a top-row select key or area, enter in the hours from GMT for your location and press CMD.

7. Using CMD, navigate to House Code.

8. Press a top-row select key or area and enter a house code from 1-50 and press CMD.

9. Using CMD, navigate to Enter Weather ZIP Code.

10. Press a top-row select key or area and enter a local ZIP code to display weather alerts on the keypad.

Add an Area

1. Navigate to Area Information and press a top-row select key or area.

2. Enter an Area Number and press CMD.

3. Press CMD until Exit Delay displays.

4. Press a top-row select key or area or area and enter a time between 45 and 250 seconds.

5. Press a top-row select key or area to clear any text and enter in a new Area Name.

6. Exit Area Information and navigate to Stop to save changes.

Add a Wireless Zone

1. Navigate to Zone Information and press a top-row select key or area.

2. Enter a Zone Number and press CMD.

3. Press a top-row select key or area and enter a Zone Name.

4. Press a top-row select key or area and select a Zone Type.

5. Press a top-row select key or area to display the list of available areas and select the appropriate area.

6. At the Next Zone? prompt, select NO to program a wireless zone.

7. At the Wireless? prompt, select YES and press CMD.

8. Enter a Serial Number and press CMD to navigate to the Next Zone? prompt.

Add a Wired Zone

1. Add Zone 1 as a hardwired zone in the Zone Information menu.

Standard Walk Test

1. At the keypad, enter 8144 (WALK) to enter the Walk Test menu.

2. Select STD to begin the standard walk test.

3. Trip wired and wireless zones to complete the standard walk test.

Wireless Check-In Test

1. At the keypad, enter 8144 (WALK).

2. Select WLS to begin the wireless check-in test.

PIR Walk Test

1. At the keypad, enter 8144 (WALK).

2. Select PIR to begin the PIR walk test.

Diagnostic Menu

1. At the keypad, enter 2313 (DIAG) to enter the Diagnostic Menu.

2. Press CMD until the keypad displays Comm Status, then press a top-row key or select area.

3. Press 1 to test Communication Path 1.

4. When the signal strength is displays, select YES to continue the test.

5. Press CMD and select Stop to exit the Diagnostic Menu.

Create a Profile

1. At the keypad, press CMD until the User Menu? prompt displays.

2. Select YES and enter 99+CMD to enter the User Menu.

3. Using CMD, navigate to Profiles? and press a top-row select key or area.

4. Select Add and enter 11 to create Profile 11.

5. Press a top-row select key or area to name the profile Access.

6. Assign Arm/Disarm Area 2 and press CMD.

7. Assign Access Area 2 and press CMD.

8. Press CMD until Disarm? displays and select YES.

9. Navigate to Door Access and confirm it is set to YES.

10. Navigate to First Access Schedule and press the third select key or area to enter the schedule number for the access schedule.

11. List will show the schedule names.

12. Press CMD until Profile 11 Added is displayed.

13. Create another profile named Management using Profile 12.

Add a User Code with PIN

1. Enter the User Menu and navigate to the User Codes? prompt.

2. Press a top-row select key or area to add a User Code.

3. Select Add.

4. Select the User Number and press CMD.

5. Enter in a 5-digit user code and press CMD.

6. Press a top-row select key or area to add a User Name and press CMD.

7. Press a top-row select key or area to enter 12 to assign Profile 12 to this user.

8. Press CMD until User Added displays.

Add a User Code with Card

1. Enter the User Menu and navigate to the User Codes? prompt/

2. Press a top-row select key or area to add a User Code.

3. Select Add.

4. Select the User Number and press CMD.

5. Scan card by waving it over the blue status LED.

6. Press a top-row select key or area and add a User Name and press CMD.

7. Press a top-row select key or area and enter 11 to assign Profile 11 to this user.

8. Press CMD until User Added displays.

Create a Schedule

1. At the keypad, press CMD until the User Menu? prompt displays.

2. Select YES and enter 99+CMD to enter the User Menu.

3. Using CMD, navigate to Schedules? and press a top-row select key or area.

4. Select Times.

5. To create a time schedule, select Add.

6. Press 1 to create Schedule 1.

7. Press a top-row select key or area to name the schedule Access.

8. Press CMD and select a day of the week.

9. Enter the Begin and End times for the chosen day.

10. Set times for each day of the week.

11. Create another schedule names Lights.

Program an Annunciator Output

1. Remove all power from the panel.

2. Connect a 4-wire harness to the Outputs header on the panel.

3. Connect the POSITIVE leg of the LED to the Red terminal on the panel.

4. Connect the other leg of the LED to Output 3 on the panel.

5. Power the panel back up.

6. At the keypad, enter 6653 (PROG) to enter the panel programmer.

7. Navigate to Area Information and press a top-row select key or area.

8. Navigate to settings for Area 1.

9. Navigate to Armed Output and press a top-row select key or area to clear the current setting.

10. Set the output to 3.

11. Navigate to Stop to save changes and exit the panel programmer.

12. Arm Area 1 to confirm the output is working.

Program a Relay

1. Remove all power from the panel.

2. Plug a Model 305 relay into the socket for Output 1.

3. Connect the Model 431 harness to the header between the output sockets.

4. Connect the POSITIVE leg of the LED to the Red terminal on the panel.

5. Connect the other leg of the LED to the second Orange wire on the harness.

6. Connect the second Gray wire to the Black terminal on the panel.

7. Power the panel back up.

8. At the keypad, enter 6653 (PROG) to enter the panel programmer.

9. Navigate to Zone Information and press a top-row select key or area.

10. Navigate to settings for Zone 1.

11. Program Zone 1 as a Night type zone in Area 1.

12. At the Next Zn? prompt, select NO.

13. Navigate to Disarmed Short and press CMD until Output No is displayed.

14. Press a select key or area to set the output to 1.

15. Set the output action to Follow.

16. Navigate to Stop to save changes and exit the panel programmer.

17. Press the button to trip Zone 1.

Create an Output Schedule

1. Enter the User Menu and press CMD until Schedules? is displayed.

2. Press a select key or area, then select Times, then Add.

3. Enter 1 for the schedule number, then name the schedule LED.

4. Set Begin and End times for each day of the week.

5. When all times are set, press the Back Arrow until Saving Schedules displays.

6. Re-enter the schedule programming section. Press CMD and select Output.

7. Enter Output 1, then Schedule 1.

8. Press the Back Arrow to exit schedule programming.

9. Advance panel time to test the begin and end times for the schedule.

Select the System Type

1. At the keypad, enter 6653 (PROG) to enter the panel programmer.

2. Navigate to System Options and press a top-row select key or area.

3. Press a top-row select key or area to display the list of system types.

   • Options include Area, All/Perimeter, and Home/Sleep/Away.

4. Exit System Options and navigate to Stop to save changes.
